Digital Industrial X-Ray & CT for part sorting is the fastest, most conclusive, and cost effective method to non-destructively qualify parts for conformance to a variety of standards. From detecting porosity, cracks, foreign material, broken wires, inadequate assembly, and more, Haven Metrology has the certifications and experienced required to get your project done – quickly, properly, and affordably. Sound too good to be true? Check out our reviews.

We have performed a large variety of production level sorts. Below are some practical examples:

8,000 EV Battery Module Scans – 3D CT for cell tears
1,800 Large EV Circuit Boards – 3D CT for proper electronic alignments
22,000 Safety Critical Medical Castings – 2D X-Ray for fractures and porosity
9,000 Wire Harnesses – 2D X-Ray disconnected wires
20,000 Aviation Engine Fans – 2D X-Ray assembly alignments
800 Automotive Shifter Housings – 3D CT dimensional sort


Benefits of HMS X-Ray & CT

  • Custom Modular Fixturing and Certifications for repeatability
  • Well rounded variety of certifications and accreditations
  • Qualified operators, 24/7 production capabilities
  • Premium equipment for speed and quality optimization
  • Automation options to reduce labor costs
  • Expedite & 1 Day Lead available

Serving clients across the globe, Haven Metrology is an ISO/IEC 17025:2017 accredited, ASNT & NAS410 certified, and ITAR registered and compliant contract inspection lab using CMMs with PC-DMIS & Calypso, 3D Scanning with PolyWorks, Industrial CT Computed Tomography & X-Ray Radiography with Volume Graphics, Reverse Engineering with Geomagic Design X, High Accuracy Vision services, and a wide variety of hand measurement tools.
