Merry Christmas from the team at Haven Metrology to you.

Enjoy this multi-material CT scan of a music box snow globe. This is a particularly difficult project because there are so many materials with varying density. We were able to segment them all, including the music box.

santa

We overlay two images – the exterior against the same parts with transparency – so you can see where different features are located.

The music box is full of details that are only possible to scan using Industrial CT – the coil, sprocket, and other features out of line of sight.

ct-slice

You can explore the exterior and interior of this snow globe yourself. Press the play button below to load it into your browser using SketchFab.
